Planet VC-203PT User Manual

7
1.3 Product Specications
Model VC-203PT VC-203PR
Hardware Specications
Interface
Copper
10/100Base-TX RJ-45
Auto-negotiation/
Auto-MDI/MDI-X
802.3at/af PoE Input
10/100Base-TX RJ-45
Auto-negotiation/
Auto-MDI/MDI-X
802.3at/af PoE Output
Coaxial
BNC, female
Power over Coaxial Output
BNC, female
Power over Coaxial Input
DC Socket
(Optional)
52~56V DC Input
DIP-Switch
2-Position DIP Switch
 Selectable CO or CPE
mode (Default: CPE)
 Selectable Band plan:
Asymmetric or
Symmetric (Default:
Asymmetric)
2-Position DIP Switch
(Front)
 Selectable CO or CPE
mode (Default: CO)
 Selectable Band plan:
Asymmetric or
Symmetric (Default:
Asymmetric)
---
2-Position DIP Switch
(Rear)
 PoE out or DC out
(Default: PoE out)
 12V DC / 24V DC
output voltage
(Default: 12V DC)
LED Indicators
LED is Green Color
 PWR
 PoE IN
 LNK
 CO
 CPE
 LNK/ACT
 100
LED is Green Color
 PWR
 PoE IN
 PoE Out
 LNK
 CO
 CPE
 LNK/ACT
 100
ESD Protection 2KV DC
EFT Protection 2KV DC
Enclosure IP30 metal case
