6
3. Hardware Installation
Step 1:
1.InstallthebackplanetothebackoftheAP.
2 AttachtheL-typebrackettothebackplaneandfastenit.
3 PlacetheAPtothepoleandfastenitwiththeU-boltkit.
TheAPcanbemountedonthepolewithadiameterofupto2”.
L-type Bracket
U-bolt Kit
U-bolt Dimensions
