LED
STATE
FUNCTION
PWR
On
Device power on
Off Device power off
2.4GHz
On
The 2.4GHz Wi-Fi is activated.
Flash Device is transmitting data wirelessly over 2.4GHz.
Off
The 2.4GHz Wi-Fi is disabled.
5GHz
On
The 5GHz Wi-Fi is activated.
Flash Device is transmitting data wirelessly over 5GHz.
Off
The 5GHz Wi-Fi is disabled.
WAN
On
Link is established.
Flash Packets are transmitting or receiving.
Off
WAN port is not connected.
USB
On USB connection is established.
Flash
Data is being transmitted.
Off USB connection is not established.
Table 2-1 LED Indications
2.1.3 Rear Panel
The rear panel provides the physical connectors connected to the power adapter and any other network device.
Figure 2-4 shows the rear panel of the WDRT-1202AC.

Planet WDRT-1202AC Specifications

General

Brand	Planet
Model	WDRT-1202AC
Category	Network Router
Language	English
