User Manual of WDRT-1202AC
-80-
Appendix A: Specifications
Product
WDRT-1202AC
1200Mbps 802.11ac Dual Band Wireless Gigabit Router
Hardware Specifications
Interface
WAN Port: 1 x 10/100/1000 Mbps auto MDI/MDI-X RJ45 port
LAN Port: 4 x 10/100/1000 Mbps auto MDI/MDI-X RJ45 port (LAN1~4)
USB Port: 1 x USB 2.0, Type A, 5V 500mA
Antenna Gain:
2.4GHz: 2 x 5dBi external antenna
5GHz: 2 x 5dBi external antenna
Button
1 x reset button
1 x WPS/Wi-Fi button
LED Indicators
PWR x 1
WLAN (2.4GHz & 5GHz) x 2
WAN x 1
WPS x 1
Material
Plastic
Dimensions (W x D x H)
250 x 185 x 38 mm (W x D x H)
Weight
322g
Power Requirement 12V DC, 1.5A
Power Consumption
10W
Wireless Interface Specifications
Standard
IEEE 802.11ac 5GHz
IEEE 802.11a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequency Band Simultaneous 2.4GHz and 5GHz
Modulation Type
802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
Data Rates
2.4GHz up to 300Mbps
5GHz up to 867Mbps
Channel
2.4GHz
FCC (America): 2.412~2.462GHz (11 Channels)
ETSI (Europe): 2.412~2.472GHz (13 Channels)
5GHz
5.180-5.240GHz, 5.745-5.825GHz (up to 9 channels)
* The actual channels in application will vary depending
on the regulation in
different regions and countries.
Channel Width
802.11ac: 20/40/80MHz
802.11n: 20/40MHz
Max. RF Power / EIRP
2.4GHz: < 20dBm
