Planet WGR-500 Quick Installation Quide

11
5. Web-based Router Setting
 Starting Web Management
The following shows how to start up the Web Management of the Industrial
Router. Note the Industrial Router is congured through an Ethernet connection.
Please make sure the manager PC must be set to the same IP subnet address.
For example, the default IP address of the Industrial Router is 192.168.1.1, then
the manager PC should be set to 192.168.1.x (where x is a number between 1
and 254, except 100) and the default subnet mask is 255.255.255.0.
PC / Workstation
with Web Browser
192.168.1.x
Industrial Router
RJ45/UTP Cable
IP Address: 192.168.1.1
Figure 5-1: IP Management Diagram
 Logging in to the Industrial Router
1. Use Internet Explorer 8.0 or above Web browser and enter IP address
http://192.168.1.1 to access the Web interface.
2. When the following dialog box appears, please enter “admin” in both the
defaultusernameandpasswordelds.TheloginscreeninFigure5-2appears.
Default IP Address: 192.168.1.1
Default Username: admin
Default Password: admin
Figure 5-2: Web Login Screen
