6
3.1 Terminal Block Connector Pinout
To install the 3-pin Terminal Block Connector on the Industrial Router, simply follow
the following steps:
Step 1: Insert positive DC power wire into V+, negative DC power wire into V-,
and grounding wire into Ground.
V+
V
-
Ground
Step 2: Tighten the wire-clamp screws for preventing the wires from loosening
and plug them into the Wall-mount Gigabit Ethernet Router.
Note
1. The wire gauge should be in the range from 12 to 24 AWG.
2. The device must be grounded.
3.2 DC Power Jack
The WGR-500-4P/WGR-500-4P requires DC 48V~56V power input and WGR-500
requires DC 12~48V power input. Should you have the issue of power connection,
please contact your local sales representative.
2.1mm
DC Receptacle 2.1mm
+48~56V for each slot
DC receptacle is 2.1mm wide that conforms to the WGR-500 series
2.1mm DC jack's central post. Do not install any improper unit.
