FIP 4.1 Fault isolating procedure Model 61
T08012 TJ
Observed fault P ossible cause F ault isolating/repair
False jam indication Main circuit board PL60 Check for app. 24 VDC at
from Model 61. defective. connector J1 between pin
10 and common ground.
Circuit board PL61 Check for app. 24 VDC at
defective. connector J5 between pin
23 and common ground.
Start switch SW9 defective. Check for app. 24 VDC at
connector J5 between pin
15 and common ground.
Main circuit board PCB 90-1 Check for app. 30 VDC at
in collator or interface cable connector J5 between pin
defective. 1 and 16.
Staple position not Staple stop not parallel See REP 2.5.
on fold. compared to anvils.
Fold plate not in correct See REP 2.7.
position.
Fold not straight. Fold stop not in correct See REP 2.6.
position.
Side guides not straight. See REP 2.3.
Eject Idler roller not in See REP 2.12.
correct position.
Eject motor not in correct See REP 2.13.
position.
Eject Idler rollers not aligned. See REP 2.14.
Staples deformed. Staple position to anvils not See REP 2.8.
correct.
Staple pressure not correct. See REP 2.9.
STAPLER FOLDER MODEL 61 PAGE 4.4 OCTOBER-94
