FIP 4.2 Fault isolating procedure Model 60
T08012 TJ
Observed fault P ossible cause F ault isolating/repair
Belt stacker motor M5 Main circuit board PCB 60 Check for 24 VDC at
inoperative. defective. connector J6 between pin
1 & 2.
Belt stacker motor M5 Check for 24 VDC at
defective. belt stacker motor.
Staple position not Staple stop not parallel See REP 2.5.
on fold. compared to anvils.
Fold plate not in correct See REP 2.7.
position.
Fold not straight. Fold stop not in correct See REP 2.6.
position.
Side guides not straight. See REP 2.2.
Eject Idler roller not in See REP 2.12.
correct position.
Eject motor not in correct See REP 2.13.
position.
Staples deformed. Staple position to anvils not See REP 2.8.
correct.
Staple pressure not correct. See REP 2.9.
STAPLER FOLDER MODEL 60 PAGE 4.7 OCTOBER-94
