SETTINGS
D-3
MacR6-Z0 – USER MANUAL
CONFIGURATION PROCESS
1. Turn on
the
OptoBTEx
interface by
closing
ferromagnetic element to the place
marked as . On the front
the blue indicator will start to blink.
2.
Put the OptoBTEx
to the OPTICAL
INTERFACE
window. Blue LED
has to be always at
the right side of the
recorder. On the
display the icon (G)
will appear. > more details: ON
DISPLAY MENU
3.
Turn on the Data logger
configurator application.
Estabilish the connection between the
smartphone and the OptoBTEx head.
If the Bluetooth is not enabled, the
application will inform about this and will ask
for turning it on. While estabilishing
connection there is required to put PIN from
the OptoBTEx side sticker (1234) - only at
the first time.
4.
After the
connection is
estabilished,
the recorder ID
will be read. On
the display the
icon (F) will
start to blink. > more details: ON DISPLAY
MENU Readout will cause the basic
parameters configuration window appear
such as: pulse factor, gas meter counter,
connection with gas meter type.
5.
option allows for
opening window, where most common
values for most devices - i.e. data server
address can be programmed.
Choosing
allows user for additional parameters
adjustment, including factory defaults.
.
6.
To save the data press the button
By pressing
button the new window will appear
where parameters like time
synchronization are included. The
application will recognize current time
(daylight saving time, winter time).
To Next Page
