Data Management Operating Instructions MSA 2 MULTI
20
4.1 Protocol view
To view the saved protocols, press MENU once: the most recent
protocol appears as first.
 123 E-0
d110 [
+GF+
12/06/12 15:54 25°C
 123
Vo=39.5V
t =1000s
E = 200kJ P=215V
The buttons ()() allow to scroll up and down the list of
protocols, while the ()() ones allow to see all the information
related to each single protocol. the Pressing STOP/ESC (O) the
user can go back to main menu again.
In the table below are summarized the symbols used to identify
the fitting type.
Symbol Description
C
Elbow 45° - 90

Tee 90°
[
Single socket

Coupler
‡
Saddle and coupler

Reducer
J
Tapping Tee
<
Electro-thermo-
retractable sleeve
