Pneumatech AD 1250 - Installation Proposal

Instruction book
18 9828 0931 61
Reference Name
(1) Electric cable outlet
(2) Condensate drain outlet
(3) Air inlet
(4) Air outlet
(5) NPT adaptors (2X) (UL version only)
(6)
Unit measurement in mm
[x] = [inch]
3.2 Installation proposal
Transport and handling
The machine must be transported as shown in the following figure.
For machine weight, see the section “Air dryer data”.
Un
packing
Cutting the metal strapping is a dangerous operation. D
o not cut pieces in the
environment.
After removing the packing, ensure that no damage has occurred to the machine during transportation.
If you are in doubt, do not use the machine. Call your distributor’s service department or dealer.
The packing material (plastic bags, polystyrene foam, nails, screws, wood, metal strapping, and so on.)
must not be left within the reach of children or left in the environment, as they are a potential source of
danger and pollution. Dispose of these materials in the approved collection centers.
