Instruction book
24 9828 0931 61
Position of plates
The plates fitted on the compressor unit are part of the machine; they have been applied for safety purposes
and must not be removed or spoiled for any reason.
Position of the data plates
Reference Name
1 Spare plate Code 1079 9903 48
2 IN
3 OUT
4 Identification plate
