Topic Description
PDP Extended Cycle
Displays if the PDP extendend cycle is activated or not.
PDP Switching
Temperature
Displays the PDP switching temperature
PDP Alarm Offset
Displays the PDP alarm offset
INPUTS
Topic Description
Pressure Vessel A
Displays the pressure of vessel A.
Pressure Vessel B
Displays the pressure of vessel B.
Inlet Dryer
Displays the dryer inlet temperature.
Dryer Pressure Dewpoint
Displays the dryer pressure dewpoint temperature.
Emergency Stop
Displays the emergency stop status.
Remote Start/Stop
Displays the remote start/stop status.
OUTPUTS
Topic Description
Dryer Motor
Indicates that the dryer is running.
Low Pressure Alarm
Displays status of low pressure alarm.
General Shutdown
Displays status of general shutdown.
General warning
Displays status of general warning.
Pressure Relief Valve A
Displays if pressure relief valve A is present.
Pressure Relief Valve B
Displays if pressure relief valve B is present.
EVENT HISTORY
Topic Description
-
Displays a log file of all shutdowns and shows the status of the type, counters,
inputs and outputs at the moment a shutdown appeared
SETTINGS
Topic Description
Network
Displays the CAN and ethernet configuration
General
Displays settings concerning time, date, unit and display time-out
Regulation
Displays settings concerning the compressed air flow regulation
Remote Control
Displays setting concerning the remote control
Automatic Restart
Automatic Restart After Voltage Failure can only be enabled by a service
technician.
Access Key
Displays the controller access level that can be modified with password input
Main Chart
Displays the input and the range of the main chart
