9 Technical data
9.1 Reference conditions
Condition Unit 160 psi 210 psi
Effective inlet pressure of compressed air psi 101.5 181.3
Inlet temperature of compressed air ˚F 95 95
Relative humidity of the air at inlet % 100 100
Pressure dew point (PDP), standard version ˚F -40 -40
Pressure dew point (PDP), optional version ˚F -100 -100
9.2 Limitations for operation
Limitation Unit 160 psi 210 psi
Max. effective inlet pressure of compressed air psi 160 210
Min. effective inlet pressure of compressed air psi 58.0 160
Maximum ambient air temperature ˚F 104 104
Minimum ambient air temperature ˚F 35.6 35.6
Max. inlet temperature of compressed air ˚F 122 122
Min. inlet temperature of compressed air ˚F 35.6 35.6
9.3 Specific data
Standard version (PDP -40 ˚F) - 160 psi
Desiccant type: activated alumina (Al
2
O
3
)
PH 230
HE
PH 320
HE
PH 390
HE
PH 530
HE
PH 635
HE
Max. volume flow at dryer
inlet
cfm 227 318 392 530 636
Total amount of desiccant lb 309 375 441 573 661
Mass lb 750 915 981 1223 1433
Time of half a cycle s 180 180 180 180 180
Regeneration time s 145 145 145 145 145
Installed power W 63 63 63 63 63
Instruction book
2920 1891 00 57
