Standard version (PDP -40 ˚F) - 232 psi
Desiccant type: activated alumina (Al
2
O
3
)
PH 230
HE
PH 320
HE
PH 390
HE
PH 530
HE
PH 635
HE
Max. volume flow at dryer
inlet
cfm 271 381 466 636 763
Regeneration air consumption
average at max. inlet flow
% 15 15 15 15 15
Total amount of desiccant lb 309 375 441 573 661
Mass lb 750 915 981 1223 1433
Time of half a cycle s 250 250 250 250 250
Regeneration time s 195 195 195 195 195
Installed power W 63 63 63 63 63
Special version (PDP -100 ˚F) - 160 psi
Desiccant type: molecular sieves
PH 230
HE
PH 320
HE
PH 390
HE
PH 530
HE
PH 635
HE
Max. volume flow at dryer
inlet
cfm 182 254 313 424 509
Regeneration air consumption
average at max. inlet flow
% 23 23 23 23 23
Total amount of desiccant lb 309 375 441 573 661
Mass lb 750 915 981 1323 1433
Time of half a cycle s 180 180 180 180 180
Regeneration time s 145 145 145 145 145
Installed power W 63 63 63 63 63
Special version (PDP -100 ˚F) - 232 psi
Desiccant type: molecular sieves
PH 230
HE
PH 320
HE
PH 390
HE
PH 530
HE
PH 635
HE
Max. volume flow at dryer
inlet
cfm 218 305 371 509 614
Regeneration air consumption
average at max. inlet flow
% 18 18 18 18 18
Total amount of desiccant lb 309 375 441 573 661
Mass lb 750 915 981 1323 1433
Time of half a cycle s 250 250 250 250 250
Regeneration time s 195 195 195 195 195
Installed power W 63 63 63 63 63
Instruction book
58 2920 1891 00
