Humidity 90% relative humidity (non-condensing)
Power Supply
Input (Universal)
(from the power source)
AC 100–240 V, 0.4 A
50/60Hz
Included with Handy Terminal
Output (to the cradle) DC 5V , 2.0 A
Charging
Standard Charge
Standard Capacity: 2200mAh – Approx. 4 hours
High Capacity: 3300mAh – Approx. 6 hours
Spare battery
Standard Capacity: 2200mAh – Approx. 4.5 hours
High Capacity: 3300mAh – Approx. 6.5 hours
Max Charging Current 2A Max
Standby Current less than 100mA
Status LED
Green: charged
Red: charging
Communication
Interface
USB Mini-B Male connector supports data transmission of up to 12 Mbps
OR
Standard DB9 serial connector supports data transmission up to 115 Kbps
Ethernet 10/100BASE-T(support only PM260-SE)
Agency Approvals
Power Supply
UL listed
TUV licensed
Power Supply compliant to FCC part 15, Class B
Charging
CE Marking (EMC)
Fire Retardant UL 94- HB
64
