point 3 Series - Before Locating the Fixing Brackets; Adjusting the Bracket Position

32
BEFORE LOCATING THE FIXING BRACKETS
The unit should be placed on a stable, smooth surface (use the packaging).
Do not apply force onto the controls protruding from the hob.
ADJUSTING THE BRACKET POSITION
Fix the hob on the work surface by screwing 4 brackets on the bottom of
hob
(see picture) after installation.
Adjust the bracket position to suit for dierent table top thickness.
Under any circumstances, the brackets cannot touch with the inner
surfaces of the worktop after installation (see picture).
brackets
A
B
HOB
TABLE
BRACKET
HOB
TABLE
BRACKET
