58
PIPING DIAGRAMS
Check local codes.
Mixing Valve
Metal
Drain
Pan
6" (15.2cm)
Air Gap Max.
Adequate Drain
NOTE:
Follow the Mixing Valve
manufacturers instructions
when installing the
mixing valve.
(set to 120° F
[48.8° C] or lower)
Mixing Valve
NOTE:
Follow the Mixing Valve
manufacturers instructions
when installing the
mixing valve.
Figure 51: TYPICAL ONE-TEMPERATURE SYSTEM PIPING INSTALLATION (All Models)
Figure 52: SAMPLE MIXING VALVE INSTALLATION (All Models)
