THE PERFECT FIT
Edge Touring Suspension
To rsion Spring Tension
To adjust rear torsion spring t ension, rotate the two-position cam using
the engine spark plug tool.
Different rate torsion springs are available if greater tension is desired.
Refer to the setup chart on page 48 and under the hood of the
snowmobile.
The following information i s provided only as a guideline to be used
for initial suspension setup. Your setup m ay vary based on your
desired riding style.
1a - Soft Tension - long end of cam to front
1b - F irm Tension - short end of cam up
2a - Turn screw clockwise t o tighten compression (stiffen)
2b - Turn spring clockwise to tighten preload
1a
1b
2a
2b
