80
MAINTENANCE
Lubrication
Lubricate the suspension and steering components with Polaris
Premium 4 all season grease annually or about every 1000 miles
(1600 km). See page 128 for the part numbers of
Polaris-recommended products.
The illustration shows t he location of suspension and steering
components. A + indicates a grease point or fitting.
S Grease the left and right spindles. Raise the front end of the ma-
chine to permit better grease entry into the spindle area.
S Lubricate both of the front ski pivots at the fittings as shown.
S Grease the jackshaft and driveshaft clutch side bearings.
S Use an aerosol lubricant on t he steering post support bracket.
S Grease the center steering arms.
S Grease the steering post lower pivot.
S Grease the rear suspension pivot shafts (raise t he rear of unit).
A grease gun kit, complete with grease and adaptors, is available to
lubricate all fittings on Polaris snowmobiles. See page 128.
+
+
+
+
+
