ASSEMBLY NOTES
Fuel Rail Fastener Torque: 7 ft.lbs. (10 Nm) DO NOT OVERTIGHTEN!
Use extreme care when removing fuel injectors from fuel rail.
Store removed fuel injectors in clean, dry place. Never allow foreign material to enter fuel injector screens.
Clean fuel injector nozzles and screens with clean fuel.
FUEL PRESSURE REGULATOR
REGULATOR CIRCLIP
FUEL SUPPLY
FUEL INJECTORS
INJECTOR RETAINING CLIPS
FUEL RETURN
FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
5.8
2004 Four Stroke PWC Service Manual
Fuel Rail / Fuel injectors
