49
Features and Controls
Master Cylinder/Brake Fluid
Check the brake fluid in the master cylinder before each ride. If the fluid level is low add
DOT 4 brake fluid only. Do not overfill. See page 172 for the part numbers of Polaris prod-
ucts.
Hand Brake Fluid Level
1. Position the ATV on a level surface. Position the
handlebars so the master cylinder is level.
2. View the fluid level through the indicator window
on the side of the master cylinder.
3. Maintain the fluid level at or slightly above the
mark near the center of the sight glass. Do not
overfill.
Foot Brake Fluid Level
1. Position the ATV on a level surface.
2. Remove the seat and view the fluid level in the reservoir. Maintain the fluid level
between the maximum and minimum marks.
