105
MAINTENANCE AND LUBRICATION
Engine Oil L evel
Check the oil level before each use of the vehicle.
The dipstick (1) is located on the left side of the ATV.
1. Position the ATV on a level surface.
2. Start the engine and l et it idle for one minute.
3. Stop the engine and remove the dipstick. Wipe
it dry with a clean cloth.
4. Reinstall the dipstick completely.
NOTE: The dipstick must be screwed completely
in to keep the angle and depth of the stick
consistent.
5. Remove the dipstick and check the oil level.
Maintain the oil level in the safe range (2),
between the full and add marks. Do not
overfill.
6. Reinstall t he dipstick.
1
2
