123
MAINTENANCE AND LUBRICATION
Front Cab Removal
1. Remove the screws (1) from the left and right cab
mounts.
2. Remove the wire harness connector from the cab.
The connector is located under the left fender.
3. Loosen the fuel t ank cover screws (2).
4. Remove the four side panel screws (3).
5. Gently pull t he cab upward to disengage it from t he
stand-off.
Side Panel Removal
1. Unlatch and remove the seat .
2. Remove the front cab.
3. Remove the two screws (1) securing the
side panel.
4. Remove the side panel.
3
2
1
1
