Polaris Predator 90

BODY/STEERING/SUSPENSION
4.12
3. Install the handlebar. Secure the handlebar with
the clamps and bolts, but do not tighten at this
point.
4. Position and tighten the left and right side controls
and brake lever clamps.
5. Position the handlebar on the steering post and
tighten the clamp bolts to specification.
Handlebar Mounting Clamp
Bolt Torque:
84 in.lbs. (10 Nm)
6. Check freeplay of the right side and left side front
brake cables as shown. Adjust to specification.
Front Brake Lever Free Play:
.40-.80I (10-20 mm)
Front Brake Lever Travel:
50 cc= 1 1/8I (28 mm)
90 cc = 1 3/4² (45 mm)
7. Check freeplay of the rear brake cable. Adjust to
specification.
Rear Brake Lever Free Play:
.40-.80I (10-20 mm)
Rear Brake Lever Travel:
50 cc= 1 1/8I (28 mm)
90 cc = 2 1/2² (65 mm)
