Polaris RANGER 2x4 User Manual

TRANSMISSION
8.4
transmission.
Vent Tube & Air Intake Hose
4. Disconnect the transmission switch.
T ransmission Switch
5. Remove the cotter pin from the shift linkage rod.
Remove the shift linkage rod and a washer from
the bellcrank.
6. Loosen the jam nuts for the transmission cable.
Remove the cable from the mounting bracket.
Jam Nuts
7. Remove the mounting bolts from the
transmission mounting on both sides of the
transmission.
Front
