TRANSMISSION
8.10
have a regular shift dog in the location indicated by the
arrow in the photo.
Shift Fork
14. Remove the bearing from the reverse shaft with a
puller.
15. Remove the park lock engagement dog. Remove
the wave spring and reverse engagement dog.
Engagement
Dogs
16. Remove the bearing from the input shaft with a
puller.
17. Remove the snap ring and washer from the
reverse shaft.
18. Remove low gear (33T) and the needle bearing.
19. Remove the reverse gear shaft.
