TRANSMISSION
8.22
4X4 & 6X6 TRANSMISSION EXPLODED VIEW, CONT.
Ref. Qty. Description Ref. Qty. Description
1 Asm., 4x4 & 6x6 Transmission 35. 1 Gear, 47T
1. 1 Nut 36. 1 Screw
2. 5 Screw 37. 1 Cover, Bearing
3. 1 Cover 38B. 1 Ring, Retaining (6x6 only)
4. 1 Pawl, Detent 39. 1 Spacer
5. 1 O--Ring 40. 1 Bearing, Ball
6. 1 Shaft, Shift 41. 4 Shaft, Pinion, 10T
7. 1 Seal 42. 1 Washer, Thrust
8. 1 Gear, 31T 43. 1 Sprocket, 19T
9. 1 Plug, Oil Fill 44. 1 Gear, 31T
10. 1 Tube, Vent 45. 1 Shaft, Output, Main, Rear
11. 4 Bearing 46. 1 Button, Thrust
12. 1 Chain, Silent 47. AR Shim
13. 4 Shaft, Input 48. AR Shim
14. 1 Bearing 49. 1 Cover, Output, Front
15. 1 Pipe, Knock 50. 1 Screw, Tapping
16. 1 Cover, LH 51. 1 Plug
17. 1 Seal 52. AR Washer
18. 1 Drum, Shift 53. 1 Shaft, Output, Main, Front
19. 3 Fork, Shift 54. 1 Chain, Silent
20. 1 Pin, Dowel 55. 2 Sprocket, 22/22T
21. 1 Rail, Shift Shaft 56. 1 Bushing
22. 17 Engagement Dog 57. 1 Gearcase, Main
23. 1 Spring, Wave 58. 1 Washer
24. 2 Ring, Retaining 59. 1 O--Ring
25. 2 Washer 60. 1 Gear, 16T
26. 1 Gear, 33T 61. 1 Disc, Lockout
27. 4 Bearing, Needle 62. 1 Star, Detent
28. 2 Shaft, Reverse 63. 1 O--Ring
29. 2 Bearing, Needle 64. 1 Spring, Compression
30. 1 Sprocket, 24T 65. 1 Switch
31. 1 Washer 66. 1 Ring, Retaining
32. 2 Washer 67. 1 Bellcrank
33. 1 Gear, 30T 68A. 1 Nut, Nylok (4x4 only)
34. 1 Gear, 37T 69A. 1 Washer (4x4 only)
