Polaris RANGER 2x4 User Manual

Lubricant Key
GENERAL INFORMATION
1.6
MODEL SPECIFICATIONS
MODEL: RANGER 2X4............
MODEL NUMBER: A11RB42AA...
ENGINE MODEL: EH42PLE06....
ELECTRICAL FLUID Capacity Type
Flywheel I.D. FF97 Fuel Tank 8.5 gals. (32.2L)...... ..........
CDI Marking CU2570 Injector Oil N / A....... ..........
Alternator Output 250 W atts Coolant 2.25 qts. (2.1L) PP6*... ............ ..
Ignition T iming 30q BTDC@5000RPMrq Transmission 27 oz (800 ml) PPS*..... .......
Spark Plug / Gap NGK BKR5E / 0.036I (0.9mm) Gearcase Oil (Front) N/A... .
Lights: Head Dual Beam (2)--35 watt quartz Gearcase Oil (Rear) 10 oz (300 ml) ....80-90...... .
Tail 5 watts Gearcase Oil (Middle) N/A........
Brake 5 watts Engine Oil 2 qts. (1.9L) PP4*...... .......... ......
Indicator ....1watt Brake(Foot) D.O.T. 3..........................
Voltage Regulator LR39..
Start System Electric start.......
DC Outlet Dash Receptacle *PPS Polaris Premium Synthetic Gear Case Oil.........
Battery........... 30Amp(12Volt) *PP4 Polaris 0W--40 Synthetic Engine Lubricant
*PDD Premium Demand Drive Hub Fluid
*PP6 Polaris Premium 60/40 Antifreeze/Coolant
SUSPENSION / CHASSIS DRIVE TRAIN
Body Style Series 11 T ransmission Dual Sensing Automatic PVT........ .......
Front Suspension MacPherson Strut Gear Reduction-Low 8.66:1.. .
MIddle Suspension MacPherson Strut Gear Reduction-Rev 5.91:1..
T urning Radius 186I (472 cm) Gear Reduction-Hi 3.81:1..... ...
Toe Out 1/8I-1/4I (3-6.35 mm) Front Drive Ratio N/A........... ....
Ground Clearance 7.2I (180 mm) Middle Drive Ratio N/A.. ...
Front V ertical Travel 6.7I (170 mm) Final Drive Ratio 3.70:1....
Center Vertical Travel 5.25” (133 mm) Shift T ype .........InLine EZShift Hi/Lo/Reverse
Rear Suspension Swing Arm w/Dual Shocks Brake Type: Hydr aulic Foot P edal... ........
Rear Travel 6.25I (158 mm) Parking Brake Foot Actuated (Mechanical)........ .......
Shock . . . (2)--2” Twin Tubes Front & Rear Brake Fixed Disc, Hydraulic....... ..
Shock Adjustment Cam Floating Caliper..
TIRES
T ire Size - Front 25 x 10 - 12....
T ire Size - Rear 25 x 11 - 12....
Tire Pressure - F/R 8--12 psi.
Total Width 60I (152.40 cm)........
Total Length 113I (287 cm).......
Total Height 75I (190.50 cm)........
Wheel Base 76I (193 cm).......
Weight - Dry 1105 lbs. (412 kgs).......
LOAD CAPACITY
Tow Hitch Receiver Hitch.....................
Cargo Box Dimensions 58x42 x13 in...........
Cargo Box Load Capacity 850 lbs (317 kgs)......
*Payload Includes: One driver and two passengers
Hitch Tongue Capacity 75 lbs (28 kgs)..........
Hitch Towing Capacity 1400 lbs (523 kgs)..........
*Vehicle Payload 1500 lbs (681 kgs)...............
