SPECIFICATIONS
RANGER ETX
RANGER 570/570 EPS
RANGER CREW 570/570 EPS
Maximum Weight Capacity
(includes weight of operator,
passenger, cargo, accessories)
1000 lbs. (454 kg) 1250 lbs. (567 kg)
Dry Weight 1045 lbs. (474 kg) (ETX)
1075 lbs. (488 kg) (570)
1100 lbs. (499 kg) (570 EPS)
1323 lbs. (600 kg) (570)
1352 lbs. (613 kg) (570 EPS)
Test GVW - Rollover Protection
System (ROPS)
2750 lbs. (1247 kg) per OSHA 29
CFR 1928.53
2650 lbs. (1202 kg) per OSHA 29
CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 l) 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l) (570)
1.75 qts. (1.6 l) (ETX)
2 qts. (1.9 l)
Coolant Capacity 120 oz. (3.5 l) 170 oz. (5 l)
Overall Length 110 in. (279.4 cm) 142 in. (360.7 cm)
Overall Width 58 in. (147.3 cm) 60 in. (152.4 cm)
Overall Height 73 in. (185 cm) 73 in. (185 cm)
Wheelbase 73 in. (185 cm) 105 in. (266.7 cm)
Cargo Box Dimensions (Inside) 32x42x11.5 in. (81x107x29 cm) 32x42x11.5 in. (81x107x 9 cm)
Ground Clearance 10 in. (25.4 cm) 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm) 237 in. (602 cm)
Towing Capacity 1500 lbs. (680.4 kg) 1500 lbs. (680.4 kg)
Hitch Tongue Capacity 150 lbs. (68 kg) 150 lbs. (68 kg)
Max. Cargo Box Load 500 lbs. (227 kg) 500 lbs. (227 kg)
Engine Dual overhead cam, 4 valve 4 stroke single cylinder.
Displacement 567 cc (570) / 325 cc (ETX)
Bore x Stroke (mm) 99mm x 73.6mm (570) / 78mm x 68mm (ETX)
Alternator Output 460 W @ 3000 RPM
Compression Ratio 10:1 (570) / 11.5:1 (ETX)
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition Timing ECU Controlled
32° +/- 2° @ 5000 RPM
Spark Plug NGK MR7F / .031” (0.7-0.9 mm)
Lubrication System Wet Sump
Cooling Liquid
Front Suspension McPherson Strut w/8 in. (20.3 cm) of travel (570)
McPherson Strut w/9 in. (22.7 cm) of travel (ETX)
Rear Suspension Independent w/9 in. (23 cm) of travel (570)
Dual A-arm, Anti-Sway Bar w/10 in. (25.4 cm) of travel (ETX)
Throttle Body Size 42 mm (570) / 36 mm (ETX)
Ignition System Digital CDI
