9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
1.11
MASTER TORQUE TABLE
ITEM
TORQUE
A-Arm Mounting Fasteners
(Front)
42 ft-lb (57 Nm)
A-Arm Mounting Fasteners
(Rear)
40 ft-lb (54 Nm) + 90°
Air Box Mounting
Fasteners
8 ft-lb (11 Nm)
Ball Joint Fasteners
42 ft-lb (57 Nm)
Battery Bracket
Fasteners
8 ft-lb (11 Nm)
Battery Terminal Fasteners 60 in-lb (7 Nm)
Bearing Carrier M10
Mounting Fasteners
42 ft-lb (57 Nm)
Bearing Carrier M12
Mounting Fasteners
40 ft-lb (156 Nm) + 180°
Body / Floor Screws (T-40) 8 ft-lb (11 Nm)
Brake Disc Mounting Bolts 18 ft-lb (24 Nm)
Brake Bleed Screws
48 in-lb (5 Nm)
Brake Caliper Mounting
Bolts (front)
30 ft-lb (42 Nm)
Brake Caliper Mounting
Bolts (rear)
46 ft-lb (62 Nm)
Brake Disc Scraper 7 ft-lb (11 Nm)
Brake Junction Block
35 in-lb (4 Nm)
Brake Line Banjo Bolts 15 ft-lb (20 Nm)
Brake Line Flare Fittings 15 ft-lb (20 Nm)
Brake Pedal Mount Bracket
Bolts
18 ft-lb (24 Nm)
Brake Switch
15 ft-lb (20 Nm)
Cab Frame Bolts
40 ft-lb (54 Nm)
Cam Chain Tensioner
29 ft-lb (40 Nm)
Camshaft Carrier Bolts
7 ft-lb (10 Nm)
Camshaft Sprocket Bolts 11 ft-lb (15 Nm)
Clutch Cover (inner)
Screws
10 ft-lb (14 Nm)
Clutch Cover (outer)
Screws
54 in-lb (5 Nm)
Connecting Rod Bolts
Step 1: 9 ft-lb (12 Nm)
Step 2: 22 ft-lb (30 Nm)
Step 3: Tighten add’n 90°
Coolant Bleed Screw
89 in-lb (10 Nm)
Coolant Temperature
Sensor
17 ft-lb (23 Nm)
ITEM
TORQUE
CPS Retaining Bolt 9 ft-lb (12 Nm)
Crankcase Bolts M10
Torque in sequence
Step 1: 9 ft-lb (12 Nm)
Step 2: 21 ft-lb (28 Nm)
Step 3: Tighten add’n 90°
Crankcase Bolts M8
26 ft-lb (35 Nm)
Crankcase Bolts M6
9 ft-lb (12 Nm)
Crankcase Oil Gallery Plug
(M20)
22 ft-lbs (30 Nm)
Crankcase Oil Gallery Plug
(1/2 NPT)
16 ft-lbs (22 Nm)
Cylinder Head Bolts
Torque in sequence:
Step 1: 9 ft-lbs (12 Nm)
Step 2: 26 ft-lb (35 Nm)
Step 3: Additional 180°
Step 4: M6 bolts: 7 ft-lb
(10 Nm)
Differential Cover Screws
(Grade 8.8)
22 ft-lb (30 Nm)
Differential Cover Screws
(Grade 10.9)
28 ft-lb (38 Nm)
Door Fasteners
8 ft-lb (11 Nm)
Drive Clutch Retaining Bolt 96 ft-lb (130 Nm)
Drive Clutch Cover Plate
Screw
8 ft-lb (11 Nm)
Drive Clutch Shift Weight
Fasteners
20 in-lb (2 Nm)
Drive Clutch Spider
290 ft-lb (393 Nm) (Apply 0.4
mL Loctite® 620™)
Drive Clutch Spider Jam
Nut
250 ft-lb (339 Nm) (Apply 0.1
mL Loctite® 620™)
Driven Clutch Retaining
Bolt
55 ft-lb (75 Nm)
Driven Clutch Spring
Retainer Screws (non-
EBS)
12 ft-lb (16 Nm)
Driven Clutch Helix Screws
(EBS)
48 in-lb (5 Nm)
ECU Mounting Screws 24 in-lb (3 Nm)
Engine Mount / Isolator
(front)
40 ft-lbs (54 Nm)
Engine Mount to Frame
Fasteners
22 ft-lb (30 Nm)
GENERAL INFORMATION
1
