9
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
9.23
6. Fully install the stabilizer bar, bushings, bracket and
fasteners. Center stabilizer bar in the frame. Torque
mounting fasteners to specification.
NOTICE
Refer to bolt head to determine which class bolt has
been installed during manufacturing.
TORQUE
Stabilizer Bar Mounting Bolts:
Class 8.8: 17 ft-lb (23 Nm)
Class 10.9: 31 ft-lb (42 Nm)
7. Install the stabilizer bar linkage fasteners. Torque
fasteners to specification.
TORQUE
Stabilizer Bar Linkage Fasteners:
40 ft-lbs (54 Nm)
8. Lubricate the stabilizer bar bushings. See
Maintenance chapter – Grease Lubrication Points
page 2.27
STEERING / SUSPENSION
