119
MAINTENANCE
Taillight/Brakelight Lamp
Replacement
If the taillight/brakelight does not work the
lamp may need to be replaced.
1.From the rear of the taillight remove two
screws holding lens cover in place and
remove lens cover.
2.Remove lamp and replace it with recom-
mended lamp.
3.Test the taillight/brakelight to see that it’s
working.
4.Reinstall the lens cover removed in step 1.
Indicator Lamp Replacement - Style I
1.With a small, flat screwdriver gently pry
loose the indicator light cover.
2.Using a small flexible tube (such as an
oil delivery hose) grasp the burned out
lamp and remov e it.
3.Replace the removed lamp with a Polar-
is PN 4030042 (Sylvania PN 12POL).
4.Replace the indicator light cover.
Indicator Lamp Replacement - Style II
1.Follow steps 1 - 3 of Headlight Housing
Replacement on previous page.
2.Unplug light from harness, depress lock-
ing tabs and remove from pod.
3.Install new light and reassemble pod.
Lens Cover
Bulb
Style I
Depress locking
tabs to remove.
Style II
