88
MAINTENANCE
Steering
Handlebar Adjustment
Your ATV has handlebars which can
be adjusted for your personal fit.
1.Locate handlebar bolts. On mod-
els with a headlight pod, it will be
necessary to remove the upper
headlight pod. On other models
remove the handlebar cover.
2.Loosen the four bolts.
3.Adjust handlebarto desiredheight.
Be sure handlebars do not hitgas
tank or any other part of machine
when turned fully to left or right.
4.Torque handlebar adjuster block
bolts to 10 to 12 ft. lbs.
NOTE: Tighten bolts so there is an
equal gap at the front and rear of the
handlebar block. Improper gap will
result in improper fit of upper pod.
WARNING
Improper adjustment of the handlebars or incorrect torquing of the adjuster block
tighteningbolts can cause limited steeringorloosening ofthehandlebars,resulting
in loss of control and possible serious personal injury or death.
