13
SAFETY WARNING AND OPERATION DECALS
ALL WHEEL
DRIVE
SWITCH
Do not push switch to
engage AWD if the rear
wheels are spinning.
This may cause severe
drive shaft and clutch
damage.
See y our Owner’s
Manual.
7074935
MANUFACTURED
BY: POLARIS IND
DATE:
VIN:
THIS VEHICLE IS AN ALL TERRAIN VEHICLE AND
IS NOT INTENDED FOR USE ON PUBLIC ROADS.
PRINTED IN U.S.A.
7077185
CE VÉHICULE EST UN VÉHICULE TOUT TERRAIN
QUI NiEST P AS DESTINÉ À ÊTRE UTILISÉ SUR
LES CHEMINS PUBLICS.
ATTENTION
Specific carburetor jetting and adjustments are required depending on
temperature and altitude. See your Owner’s Manual.
Factory setting:
40° to 80° F. at 0-3000 feet. (+5° to 26° C. at 0-900 meters). 7073761
TRAILER MAX.
WEIGHT 850 LBS.
HITCH MAX. VERTICAL
WEIGHT 30 LBS.
POIDS MAX. DE
REMORQUE 386 KG.
POIDS MAX.
VERTICAL D’ATTACHE
14 KG.
OVERRIDE
SWITCH
Reverse override
and all wheel drive
activation in reverse
is controlled by the
override switch.
See your Owner’s
Manual.
7076273
Reverse Speed is
limited.
Reverse override is
controlled by the
override switch.
See your Owner’s
Manual.
OVERRIDE
SWITCH
7076274
AWD M odels 2WD Models
7077542
TRAILER MAX WEIGHT:
1250 LBS. (568 KG) ON LEVEL GROUND
850 LBS. (368 K G) UP TO 15° GRADE
HITCH MAX. VERTICAL WEIGHT: 30 LBS. (14KG)
7072533
Chain Freeplay Is
Important. Adjust
Freeplay to 3/16″ -- 3 / 8 ″
DO NOT Overtension.
See Owner’s Manual.
Torque Eccentric Bolts To
60 Ft. Lbs.
7077618
