Polaris Vac-Sweep 280 - Page 7

www.polarispool.com
Install dished
side out
Serial
Number
M
A
D
E
I
N
U
S
A
M
A
D
E
I
N
U
S
A
39
23
18
16
21
15
9
10
2
4
13
16
14
32
33
25
6
24
15
13
14
19
26
28
37
34
38
33
36
35
2
17
8
5
7
11
12
18
19
20
21
22
17
29
31
20
30
17
15
18
19
32
Pool
Wall
10-foot Hose
10-foot Leader Hose
To The
Polaris
10-foot Hose
51
52
52
54
54
57
58
55
56
42
45 464443 47 48
41
40
21
17
18
19
2
2
17
1
3
2
27
49
50
17
17
1
53
Exploded Parts Diagram
English
1 K13 All-Purpose Zippered Bag* 1
2 C40 Screw, 10-32 x 3/8" SS Pan 20
3 K5 Top 1
4 A20 Float, Head 1
5 9-100-3105 Sweep Hose Scrubber* 1
6 B25 Orifice Tip w/Orifice Tip Guard 1
7 B5 Sweep Hose Complete* 1
8 B10 Wear Rings* 8
9 B15 Sweep Hose Attach Clamp 1
10 B20 Adjust. Screw, Sweep Hose 1
11 K30 Feed Pipe with Elbow 1
12 K20 Vacuum Tube 1
13 C66 Axle, Large (w/Sand/Gravel Grd) 2
14 C76 Screw, 10-32 x 7/8" SS Pan 10
15 C45 Lock Washer for C36 7
16 C70 Axle Plate for C65/C66 3
17 C60 Ball Bearings, Wheels 8
18 C55 Wheel Screw, Plastic 4
19 C64 Wheel Washer, Plastic 4
20 C10 Tire, MaxTrax
®
*3
21 C6 Wheel, Large (No Bearings Incl.) 3
22 C65 Axle, Large (Rear Wheel Only) 1
23 C131 Thrust Jet Kit 1
24 C16 Idler Wheel, Small 1
25 C30 Screw, 4-40 x 3/16" SS Pan 1
26 C32 Screw, 6-32 x 1/2" SS Pan Head 1
27 C25 Spring for C36 1
28 C36 Swing Axle Kit 1
29 K10 Base with Bracket 1
30 K25 Water Management System 1
31 K145 Frame 1
32 C80 Ball Bearings, Turbine 2
33 C83 Turbine Shaft Tubes 1
34 9-100-7170 Hose Clamp for WMS 2
35 A40 Turbine Shaft Shield 1
36 C86 Drive Shaft Assembly 1
37 C120 Hose for C110, 7-1/2" 1
38 C110 Turbine Cover with Elbow 1
39 9-100-1018 Bag Collar 1
40 10-112-00 Restrictor Disks, Red and Blue 2
41 6-500-00 Universal Wall Fitting (UWF) 1
42 9-100-9001 UWF Connector Assembly 1
43 10-108-00 UWF Restrictor Kit 1
44 6-505-00 O-Ring, UWF/QD 1
45 9-100-9002 Pressure Relief Valve, Black 1
46 D29 Quick Disconnect, UWF 1
47 D15 Nut, Feed Hose 10
48 ** Adapter Hose, 8-1/2" 1
49 48-080 In-Line Filter Assembly 1
50 48-222 Screen, In-Line Filter 1
51 D10 Float, Feed Hose 9
52 D45 Feed Hose, 10 Ft 2
53 D20 Swivel, Ball Bearing 2
54 D50 Feed Hose, Leader, 10 Ft 1
55 G52 Back-up Valve Kit 1
56 G54 Case Kit for G52 1
57 G57 Collar, Back-up Valve 1
58 G53 Mechanism for G52 1
*Wear items not covered by warranty.
No. Part # Description Qty No. Part # Description Qty No. Part # Description Qty
