Camera/Printer Connection
Connecting with the USB Cable.
Plug USB cable into the port of your cameraUSB Series “A” plug connects to your
printer
1. Plug Series A of the USB cable into the marked socket on your printer.
Location of USB socket will vary from printer to printer.
2. Plug USB of the USB cable into the port on your camera.
O
K
This Image
All Images
All Index
PictBridge
Connected
Device Is
Connect To Device...
Please
NOTE:
• “ Device Is Connected” displays on the LCD screen, indicating a proper
connection to the printer.
• Do not connect the USB cable to the camera until PictBridge is enable and
when prompted by the “Please Connect To Device” screen. Or if you already
have connected the cable to the camera, do not plug into printer until prompt
to do so. Not following this sequence will result in connection failure.
