5.4.2 Using RS-232 interface to setup Ethernet interface
1. Connect the computer to the printer with a RS-232 cable.
2. Switch on the printer.
3. Start the Diagnostic Utility by double-clicking on the
icon.
4. Select “COM” as interface then click on the “Setup” button to setup the serial port baud rate,
parity check, data bits, stop bit and flow controlparameters.
5. Click on the “Ethernet Setup” button from printer function of Printer Configuration tab, to
setup the IP address, subnet mask and the gateway for the on board Ethernet.
35
