3.3.2 Loading the Media in Peel-off mode (Option)
1. Refer to Chapter 3.3.1 to load the
label roll. Use “Diagnostic Tool” to set
the media sensor type and calibrate the
selected sensor.
2. Pull the label through the front of the
printer and peel some labels off the liner.
3. Open the peel-off cover. Feed the
liner into peel-off cover slot.
Liner
Label
Liner
Peel-off
cover slot
18
