TECHNICAL SPECIFICATIONS
Modello NAVY-08
Channels All International Channels
Frequency Method PLL (Phase Lock Loop)
Frequency Range TX 156.025 -157.425 MHz
RX 156.300-162.000 MHz
Power Supply 4 batterie formato “AA”
Operating Temperature Da -15°C a +55°C
Dimensions 123 mm (H) x 60 mm (W) x 37 mm (D)
Weight 190g (without batteries)
Transmitter
Power Output 0.8 or 5 Watts (Switch Selectable)
Modulation Type FM
Hum and Noise Attenuation 40dB
Audio Distortion 5%
Spurious Suppression -36dBm
Receiver
Sensitivity at 12dB Sinad
0.25μV
S/N Ratio (20dB)
0.8μV
Squelch Sensitivity Threshold -8dB V(EMF)
Adjacent Channel Rejection 70dB
Audio Power Output 200mW con 10% THD
Spurious Response Attenuation 70dB
Hum and Noise Attenuation 40dB
Modulation Acceptance Bandwidth ± 7.5KHz minimum
Note: The data are typical, and the practical ones may be varied.
