Poly IP Table Microphone Port Descriptions
Ref. Number Port Description
1 Micro-USB debugging port
2 Factory restore pinhole
3 Link-local network (LLN) connection
Poly IP Ceiling Microphone Ports
The following illustration and table explain the ports on the ceiling microphone.
Poly IP Table Microphone Port Descriptions
Ref. Number Port Description
1 Link-local network (LLN) connection
2 Microphone cable connector
3 Microphone cable connector
LED Status Indicators for IP Microphones
Use the LED on the IP table and ceiling microphones to get information on the state of each device.
IP Microphone LED Status Indicators
Indicator Status
Solid then blinking white
Powering on
24
