Polycom Visual Concert VSX User Manual

Administrator’s Guide for the VSX Series
7 - 4
Content Statistics screen
Displays content format, data rate,
frame rate, and packet loss for the
call in progress. Also provides
information about the far site
systems.
1. On the Diagnostics screen,
select Call Statistics.
2. Select three times to go to
the Content Statistics screen.
Not available.
Call Detail Report screen
Displays the current Call Detail
Report (CDR) and provides access
to the archived CDR.
Not available. Select Utilities > Call Detail
Report.
For more information about this screen, see Call Detail Report (CDR) on
page 6-4.
Network Tools
Diagnostic Tool In the system’s user interface In the VSX Web
Near End Loop test
Tests whether your system is able
to make IP calls successfully.
Monitor 1 displays the video and
plays the audio that would be sent
to the far site in a call.
This test is not available when you
are in a call.
1. On the Diagnostics screen,
select Network.
2. Select Near End Loop to start
the test.
3. Press any button on the remote
control to stop the test.
1. Select Diagnostics > Network
> Near End Loop.
2. Click Near End Loop to start
the test.
3. Click Near End Loop again to
end the test.
PING test
Tests whether the system can
establish contact with a far-site IP
address that you specify.
1. On the Diagnostics screen,
select Network > PING.
2. Enter the IP address that you
wish to test.
3. Select Start.
If the test is successful, the
VSX system displays a
message indicating that the IP
address under test is available.
1. Select Diagnostics > Network
> PING.
2. Enter the IP address that you
wish to test.
3. Click the PING icon.
If the test is successful, the
VSX system displays a
message indicating that the IP
address under test is available.
Status Tools
Diagnostic Tool In the system’s user interface In the VSX Web
