Suction & Return Fittings Installation
1. Set up your pool following the pool Owners Manual instructions. Do NOT
fill water until the Filter Pump is properly installed. Locate the Outlet and
Inlet openings on the pool wall.
3. From inside the pool, install the Return Fitting
6
into the Inlet
opening.
2. From inside the pool, install the Suction Fitting
2
into the Outlet
opening.
WARNING:
CLIMBING HAZARD! PLEASE PREVENT CHILDREN FROM CLIMBING ON THE FILTER CANISTER TO GAIN ACCESS TO THE POOL.
Before assembly, take a few minutes to identify and become familiar with all the parts.
Inlet
Outlet
4
3
1
2
Outside Pool Wall
Inside Pool Wall
SETUP INSTRUCTIONS
7
6
1
4
Outside Pool Wall
Inside Pool Wall
11
9
10
Pump Installation
4. Take out the Filter Pump Assembly
w
, two Hoses
9
, four
Hose Clamps
q
and four Universal Adaptor
l
.
28
