OPERATING INSTRUCTIONS
1. Make sure all the Hoses are secured to the fittings on the pump and pool.
2. Always press down the 6-port Valve Handle before switching position.
3. Always turn off the pump power when switching position.
4. It is critical to the backwash the sand before using the pump to clean the pool water. This will
prevent fine sand to flow into the pool and also wash off any dirt or debris within the sand.
7. Fill the pool until the water level reaches the pool fill line.
8. Follow the following steps to BACKWASH the sand before first use:
• Remove the 6-Port Valve Drain Outlet Cap from the 6-Port Valve . (Optionally, a
1.5” [38mm] hose can be connected to the drain port to direct the waste water to a nearby drain.)
• Press down the 6-Port Valve Handle and turn to the “BACKWASH” position.
• Turn on the power of the Pump .
• Pool water is now circulating backward through the sand bed
to the drain outlet. Continue BACKWASH until the drain water
becomes clean and clear.
• Turn off the Pump and switch the handle to the “RINSE” position.
Turn on the Pump for ONE minute, this will clean up and
level out the sand bed. Turn off the Pump when done.
9. To start filtering the pool, turn the 6-Port Valve Handle to the “FILTER”
position and then switch on the Pump . Record down the sand tank pressure
ready from the Pressure Gauge . This reading indicates the initial tank pressure
when the sand bed is clean.
10. BACKWASH the tank when the pressure is 1-1.5 bar (14.5 - 21.8 Psi) above the
initial pressure. Or, BACKWASH the sand filter once every TWO weeks to
maintain water cleaniness.
13
11 10
17
17
17
17
17
12
14
19
19
19
14
19
POWER SWITCH
Outlet port
Inlet port
19
