Polygroup SUMMER WAVES Series User Manual

WINTERISING, DISASSEMBLY & STORAGE
REPLACEMENT PARTS ORDERING INFORMATION
1. First, unplug the Power Cord of the system.
2. Loosen all Hose Clamps . Remove the Hose and allow water to drain out.
3. Remove Drain Valve Cap from the Sand Tank and allow water to drain out, and the tighter back the Drain Valve Cap onto the
drain valve on the Sand Tank .
4. Clear and lubricate all Fitting O-Rings with petroleum jelly and then place the sand filter pump in a safe place.
15
3 3
2
2
13
18
14
17
OWNER’S MANUAL
ST1600
Key#
ST1100
PART # PART #
Description
Sand Tank Base
Sand Tank
Drain Valve Cap
6-Port valve Drain Outlet Window
Center Pipe
Sand Guard
Clamp
CAM-SHAFT Bolt Cap
6-Port Valve O-Ring
6-Port Valve
6-Port Valve Drain Outlet Cap
Pressure Gauge
102” Hoset
ST1100 14” Hose
ST1600 12” Hose
Hose Clamp
Locking Pin
Pump
1.5” Fitting O-Ring
6-Port Valve Handle
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
P58PP1782E09
P58000000W05
P58PF0800W05
P58PF8960C01
P586402000W1
P58PF8891P01
P58897023E09
P58PP2021K01
P58135001K01
P58PF8880E09
P58PF8910E09
P58340000000
P584150004W1
P584150014W1
P5842504500A
P58PP1759E09
P530C202SGW5
P58037000K01
P58PF8950E09
P58PP2884A09
P58000001W05
P58PF0800W05
P58PF8960C01
P586402001W1
P58PF8891P01
P58897023E09
P58PP2021K01
P58135001K01
P58PF8880E09
P58PF8910E09
P58340000000
P584150004W1
P584150012W1
P5842504500A
P58PP1759E09
P530C202SGW5
P58037000K01
P58PF8950E09
