7HFKQLFDO6SHFLILFDWLRQV
3KDVH) UHT XHQ F\5H VSR QVH
With the low pass filter switched off, the vibrometer behaves as a system of constant
time delay i.e. the phase shift is proportional to the frequency. The phase shift
depends, however, on the measurement range set. .
+DUPRQ LF'LVWRUWLRQV
Velocity
decoder
Measurement range
Time delay t
d
(typ.)
Specific phase roll-off p
d
(typ.)
µ
s °/kHz
OVD-01 1 23.9
8.6
57.1
2.56
25 and 125 6.0
2.15
1,000 5.2
1.9
OVD-02 5 6.4
2.3
25 and 125 1.9
0.7
1,000 0.9
0.33
Velocity
decoder
Measurement range THD @ f = 1kHz
10%...90% of full scale range
OVD-01 1 < 0.25% (<
52dB)
5; 25; 125 and 1,000 < 0.10% (<
60dB)
OVD-02 5 and 25 < 0.20% (<
54dB)
125 and 1,000 < 0.30% (<
50dB)
mm
s
----------
V
mm
s
----------
V
