)DXOW'LDJQRVLV
&KHFNOLVWIRU)DXOW 'LDJQRVLV
&RQWUROOHU2)9ZLWKWKH 6HQVRU+HDG2)9
Serial Number Controller:
Serial Number Sensor Head:
OFV-303 OFV-353
The serial numbers can be found on the back of the instruments and also on the inside cover of
this manual.
Target Actual
1. Is the L ED POWER on the front of the controller lit up? Yes
2. Is the L ED LASER on the back of the sensor head lit up? Yes
3. After approximately 20 minutes operation, does the housing of the sensor
head feel warm to the touch as normal?
Yes
4. Is the laser beam emitted? Yes
5. Does the signal level display on the back of the sensor head react? Yes
6. Does the signal level display on the display of the controller react? Yes
7. Does the output signal VELOCITY OUTPUT on the front of the controller
react to the movement of the reflective film?
Yes
8. If the output signal does not react: How high is the DC offset? <20mV
9. Is the output signal noisy when the laser beam is blocked? Yes
10. Only for controller with displacement decoder:
Does the output signal DISPLACEMENT OUTPUT on the front of the con-
troller react to the movement of the reflective film?
Yes
11. How high are the voltages at the Sub-D jack INTERFEROMETER on the
back of the controller?
Pin 1, 4, 7, 8 and 15 GND
Pin 3, 6 and 9 +16.0V
Pin 2 +5.0V
Pin 13 -5.2V
Pin 5 and 10 -15.0V
Further observations:
