POMCube iCAN NetZero Plus Series - Page 24

20
Cooling
Passive cooling through aluminum
heatsinks, external weatherproof fan to
improve performance
Protection
Rating
NEMA 4X (IP65)
Altitude
≤9842 ft (3000 m)
Noise Emission
< 55 dB(A)
Standards
Compliance
EMC
FCC Part 15 Class B
Grid Connection
Standards
IEEE 1547A, Rule 21
Safety
UL9540, UL1741, UL1741SA, UL1998, CSA
C22.2
Lithium Iron Battery System
Electrical
Cell Chemistry
Lithium Iron Phosphate (LiFePO
4
)
Nominal
Capacity
52 Ah / 20 kWh
Usable Energy
18.5 kWh
Nominal Voltage
384 Vdc
Charge Voltage
420Vdc
Operating
Voltage Range
360 ~ 438Vdc
Continuous
Power
12.5kW
Rated Current
32A
Peak Power
20kW @ 1s
Max. Short
Circuit Current
80A @ 200ms
Protection
Over/Under
Temperature
Yes
Over/Under
Voltage
Yes
Over Current
Yes
