POMCube iCAN NetZero Plus Series - Page 40

36
M
120/240V split-phase
GRID
GND
Sub Panel (120/240V)
Main Panel
120/240V
split-phase
100A
120/240V
split-phase
DC Power Line
AC Power Line
Comm. Line
Router
NetZero Plus
PE
Solar Panel String #4
Solar Panel String #3
Solar Panel String #2
Solar Panel String #1
RSD Initiation Device
Option1
(Near Service Switch)
RSD Initiation Device
Option2
(Near Service Switch)
BAT
BAT-REF
BAT+
32A
32A
100A
GRID
LOAD
GEN
L1
L2N L1
L2N
L1
L2N
L1
N
L2
L1 N
L2
PV
PV1+
PV1- PV2+
PV2-
RSD
+ + + +
- - - -
CAN
S
ingle
line diagram for partial backup application with solar panels for grid
-
tied homes
NOTE
: If smaller
-
size wires and breakers are to be
used for AC connection, grid output current can be configured via the APP.
NOTE
: This diagram is for reference
only, not for construction.
