EXPLODED VIEW
IMPORTANT
These accessories and attachments are recommended for use with your PondMAX product specified in this manual. The use of any other accessories or attachments
might present a risk of injury to persons. Only use the accessory or attachment for its stated purpose.
Front Fiter Screen - for Sponge
Sponge
Flow Control Knob (EV700 - EV1200 Only)
Front Fiter Screen - with Hole For Flow
Control (EV700 - EV1200 Only)
Blanking Cap for Hole in Front Filter Screen
(optional)
1” Coupling Fitting x2 - for Inlet & Outlet
Impeller Cover Housing
Impeller Assembly
Impeller O’ring
Base Plate with Rubber Feet
Pump Motor Body
1” x 1-1/2” Reducer Bushing Fitting
Washer - for Locking Nut (Red)
3/4”, 1”, 1-1/4” & 1-1/2” Barbed Hosetail with
Locking Collar
1
2
3
4
Not
Shown
5
6
7
8
9
10
11
12
13
NOTE: Parts and features dier from model
to model. All images used are for illustrative
purposes only. Not all features depicted
apply to all models in the range and these
are subject to change.
